◆Working mode: Normal mode, standby mode
◆Storage medium:USB2.0 is vailable.
◆Support multi format: MP3/WMA/JPEG/MEPG4(AVI:Div‐X / X‐Vid)/MPEG2（DVD:VOB/MPG2）/MPEG1
（VCD:DAT/MPG1）/MOV etc.
◆Video standard:PAL/NTSC/automatic
◆Video output:Support 1080P（Max. Resolution ratio is 1920*1080 Progressive） and 1080I（ Max 1080i,Resolution ratio is 1920*1080 Interlace）
◆Audio output:Dual channel stereo output 2X5W,SNR 85dB
◆Repeat mode:Single repeat/Folder repeat/All repeat.
◆OSD language:Chinese, English etc
◆Remote control:Infrared remote control
◆Time setting:Available
◆Rolling Subtitle:Available
◆Memory play:Available
◆Real‐time clock:Available
◆Automaticly copy:Some filename will be cover, different filename will be copy
◆Button expand:Support additional button expand,support HDMI signal input
◆Divide screen area setting: Available
◆Playing in playing setting: Available
◆Timer function:Power on or Power off
system with user set time(MAX 5 group)
| Specification | |||||||
| Model | CW-AD32OC-W | ||||||
| Size | 32″ | 43” | 49” | 55” | 65” | 75” | 85 |
| Resolution | 1920*1080 | 3840*2160 | |||||
| Brightness | 350 cd/㎡ (Standard)，up to 800 cd/㎡ | ||||||
| Display Area | 698.4*392.9 mm | 940.89*529.2 mm | 1073.78*604 mm | 1209.6*680.4 mm | 1428.48*803.52 mm | 1649.66*927.94 mm | 1872*1053 mm |
| Ratio | 16:9 | ||||||
| View Angle | 89/89/89/89 (Typ.)(CR≥10) | ||||||
| Contrast | 1200:1 | 1200:1 | 1200:1 | 1200:1 | 1300:1 | 1300:1 | 5000:1 |
| Response Time | 6.5ms | 8ms | 8ms | 8ms | 6ms | 8ms | 6.5ms |
| Color | 16.7M , 68% NTSC | 16.7M , 72% NTSC | 16.7M , 68% NTSC | 16.7M , 76% NTSC | 1.07B , 71% NTSC | 16.7M , 76% NTSC | 1.07B , 79% NTSC |
| Dimension | 764.3*461*56.3 mm | 1105*593*56.3 mm | 1135.8*668*56.3 mm | 1275.5*747*56 mm | 1450*875*59.4 mm | 1706*986*85 mm | 1951.6*1125*92 mm |
| Net Weight | 13.5 KG | 22 KG | 26.5 KG | 32.5 KG | 51 KG | 75 KG | 100 KG |
| Gross Weight | 15 KG | 25 KG | 35.5 KG | 37.5 KG | 56 KG | 82 KG | 110 KG |
| Paper Case Size | 860*128*555 mm | 1100*128*687 mm | 1235*128*764 mm | 1370*128*840 mm | 1587*128*963 mm | 1805*200*1110 mm | 2055*210*1250 mm |
| Max consumption | ≤35W | ||||||
| Standby consumption | ≤1W | ||||||
| Working Temp | 0℃~50℃ | ||||||
| Storage Temp | -20℃~60℃ | ||||||
| Power Supply | AC100~240V 50/60HZ | ||||||
| Package | Standard export wooden case outside,paper case with EPE inside | ||||||
| Warranty | LCD screen 1 year warranty , the rest of devices 3 year warranty | ||||||
| Media player | Android OS / X86 / Stand-alone ,USB plug&play | ||||||
| Interface | USB-input*2 HDMI-output*1 TF card slot*1 RJ45*1 | ||||||
| CPU | Android ( RK3188 / RK3288 / RK3399 , A40 / A64 / A83 ) ; X86 ( Intel / AMD ) | ||||||
| RAM | Standard:4GB DDR3 ,8GB DDR3 | ||||||
| Storage | Standard:8GB /16GB / 32GB | ||||||
| OS | Android 7.1 ; Win OS | ||||||
| Play mode | Support horizontal and vertical screen playback timed play,program shedule | ||||||
| WIFI | 8.2.11*1 bgn(external Wifi antenna) | ||||||
| Video formats | Support MPEG-1、MPEG-2、WMV9、AV(3.11)、XVID、H264、1080P/60 | ||||||
| Image format | Support BMP、JPEG、PNG、GIF | ||||||
| Ethernet | 1,10M/100M Ethernet,RJ-45 Port | ||||||
| 3G/4G(Optional) | 3G:Support WCDMA/CDMA 2000 4G:FDD-LTD/TDD-LTE(4G can support 100Mbps download speed,upload speed can be at 20Mbps) | ||||||
| Speaker | 80hm 5W*2 | ||||||
| Online upgrade | Supported | ||||||
| Others | Support USB Upgrade, Upgrade through network | ||||||
