| Model |
CW-TK32OC-IF |
CW-TK43OC-IF |
CW-TK49OC-IF |
CW-TK55OC-IF |
CW-TK65OC-IF |
CW-TK75OC-IF |
CW-TK85OC-IF |
| Size |
32″ |
43” |
49” |
55” |
65” |
75” |
85” |
| Resolution |
1920*1080 |
3840*2160 |
| Brightness |
350 cd/㎡ (Standard)，up to 800 cd/㎡ |
| Display Area |
698.4*392.9 mm |
940.89*529.2 mm |
1073.78*604 mm |
1209.6*680.4 mm |
1428.48*803.52 mm |
1649.66*927.94 mm |
1872*1053 mm |
| Ratio |
16:9 |
| View Angle |
89/89/89/89 (Typ.)(CR≥10) |
| Contrast |
1200:1 |
1200:1 |
1200:1 |
1200:1 |
1300:1 |
1300:1 |
5000:1 |
| Response Time |
6.5ms |
8ms |
8ms |
8ms |
6ms |
8ms |
6.5ms |
| Color |
16.7M , 68% NTSC |
16.7M , 72% NTSC |
16.7M , 68% NTSC |
16.7M , 76% NTSC |
1.07B , 71% NTSC |
16.7M , 76% NTSC |
1.07B , 79% NTSC |
| Dimension |
764.3*461*56.3 mm |
1105*593*56.3 mm |
1135.8*668*56.3 mm |
1275.5*747*56 mm |
1450*875*59.4 mm |
1706*986*85 mm |
1951.6*1125*92 mm |
| Net Weight |
13.5 KG |
22 KG |
26.5 KG |
32.5 KG |
51 KG |
75 KG |
100 KG |
| Gross Weight |
15 KG |
25 KG |
35.5 KG |
37.5 KG |
56 KG |
82 KG |
110 KG |
| Paper Case Size |
860*128*555 mm |
1100*128*687 mm |
1235*128*764 mm |
1370*128*840 mm |
1587*128*963 mm |
1805*200*1110 mm |
2055*210*1250 mm |
| Max consumption |
≤35W |
|
|
|
|
|
|
| Standby consumption |
≤1W |
| Working Temp |
0℃~50℃ |
| Storage Temp |
-20℃~60℃ |
| Power Supply |
AC100~240V 50/60HZ |
| Package |
Standard export wooden case outside,paper case with EPE inside |
| Warranty |
LCD screen 1 year warranty , the rest of devices 3 year warranty |
| Media player |
Android OS / X86 / Stand-alone ,USB plug&play |
| Interface |
USB-input*2 HDMI-output*1 TF card slot*1 RJ45*1 |
| CPU |
Android ( RK3188 / RK3288 / RK3399 , A40 / A64 / A83 ) ; X86 ( Intel / AMD ) |
| RAM |
Standard:4GB DDR3 ,8GB DDR3 |
| Storage |
Standard:8GB /16GB / 32GB |
| OS |
Android 7.1 ; Win OS |
| Play mode |
Support horizontal and vertical screen playback timed play,program shedule |
| WIFI |
8.2.11*1 bgn(external Wifi antenna) |
| Video formats |
Support MPEG-1、MPEG-2、WMV9、AV(3.11)、XVID、H264、1080P/60 |
| Image format |
Support BMP、JPEG、PNG、GIF |
| Ethernet |
1,10M/100M Ethernet,RJ-45 Port |
| 3G/4G(Optional) |
3G:Support WCDMA/CDMA 2000 4G:FDD-LTD/TDD-LTE(4G can support 100Mbps download speed,upload speed can be at 20Mbps) |
| Speaker |
80hm 5W*2 |
| Online upgrade |
Supported |
| Others |
Support USB Upgrade, Upgrade through network |
